Description
- Adopting arbitrary positioning sliding door system
- The shell is welded by cold-rolled plates, the surface is electrostatically sprayed, and the work surface is SUS304 brushed stainless steel, which is corrosion-resistant and easy to clean.
- The lighting and sterilization systems are interlocked safely, and have the timing function of the ultraviolet lamp (except 1BU, 1CU)
- Digital display LCD control interface, more user-friendly design
- The vertical quasi-closed table top and the formation of a downward flow air curtain in the operation room can effectively prevent the input of external air and the operation area is clean
- Equipped with HEPA high-efficiency air filter, with primary filter for preliminary filtration, which can effectively extend the high-efficiency filter
Technical Specifications
| Model | YR05731 |
| Cleanliness Level | Class 100@≥0.5μM (US Federal 209E) |
| Number of Colonies | ≤0.5pcs/dish·hour (Φ90mm culture plate) |
| Average Wind Speed | 0.25～0.45m/s |
| Noise | ≤62dB（A） |
| Vibration Half Peak | ≤5μM（x、y、z direction） |
| Illuminance | ≥300Lx |
| Power Supply | AC single phase 220V/50Hz |
| Maximum power | 640W |
| Weight | 160kg |
| Work area size
W1×D1×H1 |
1770×510×600
1800×740×1440 |
| Dimensions | Double single |
| High efficiency filter specification and quantity | 1700×560×50 |
| Specification and quantity of fluorescent lamp/ultraviolet lamp | 20W×1
36W×1 |
