Inverted Metallurgical Microscope YR0258

ManufacturerKalstein

Description

YR0258 inverted metallurgical microscope with stable support structure, advanced stage design and operation. It is widely used in institute and laboratory to identify the structure of various metals and other materials.

  • Infinite optical system for high optical image quality
  • Eyepiece Eyepiece EW10x/20mm
  • Infinity PlanMetallurgicalCoverless achromatic objective
  • Kohler 6V30W external lighting halogen lamp
Technical Specifications
Model YR0258
Optical System Infinity Optical System
Head Seidentopf Trinocular Head, 30° Inclined, Interpupillary 48~75mm, Diopter Adjustable
Eyepiece Extra Wide Field Eyepiece EW10x/20mm, High Eyepoint
Nosepiece Quintuple Nosepiece
Objective Infinity Plan MetallurgicalCoverless Achromatic Objective 4x/0.1/∞/-, W.D.17.3mm
10x/0.25/∞/-,W.D.10.2mm
20x/0.4/∞/-,W.D.5.1mm
40x/0.65/∞/-, W.D.0.52mm
Focusing Coaxial Coarse & Fine Adjustment, Coarse Stroke 37.7mm Per Rotation, Fine Stroke 0.2mm Per Rotation
Working Stage Plain Stage 160*250mm With Slide Clips
Polarizing Polarizing Attachment
Filter Green, Blue, Yellow, Ground Glass, Dia.45mm
Illumination External Kohler Illumination, Halogen Lamp 6V30W, Brightness Adjustable
Optional Accesories
Objective Infinity Plan MetallurgicalCoverless Achromatic Objective 5x/0.12/∞/-, W.D.15.4mm YR0258-op1
50x/0.75/∞/-, W.D.0.32mm YR0258-op2
80x/0.9/∞/-, W.D.0.20mm YR0258-op3
100x/0.9/∞/0, W.D.0.7mm YR0258-op4
Wokring Stage Attachable Mechanical Stage, X-Y Coaxial Control, Moving Range 120*78mm YR0258-op5
Auxiliary Stage 70*180mm YR0258-op6
Adapter Photo Adapter YR0258-op7
C-Mount 1.0x YR0258-op8
C-Mount 0.5x YR0258-op9

Additional information

Weight 15 kg
Dimensions 46,8 × 39,7 × 66,5 cm
