Description
- Front Panel
- Liner and guide baffles 5mm thick anti melamine board
- (Window) 5mm thick tempered glass
- Laboratory dedicated PP Cup
- Built.in drain pioe
- Lower Side Plate
- Lower back plate
- Lower Movable floor
- Built in axial fan, air collector and anti-corrosion hose
- With wind regulator
- Upper side panel (1.2mm thick galvanized steel plate, epoxy sprayed outiside)
- Built in LED tube
- Fan and lamp switch
- Multifunctional splash proof socket
- 12.7mm corrosion proof solid core, physical and chemical board mesa
- Door frames and door panels
- Adjusting foot
Technical Specifications
| Model | YR05820 | YR05821 | YR05822 | |
| External Size (W*D*H) (mm) | 1200*800*1500 | 1500*800*1500 | 1800*800*1500 | |
| Internal Size (W*D*H) (mm) | 950*700*1150 | 1250*700*1150 | 1550*700*1150 | |
| Work Surface Height | 800mm | |||
| Max Opening of window | 750mm | |||
| Air Velocity/Exhaust air volume | 0.4-0.6m/s,800-1000m³/h | |||
| Noise | ≤60dB | |||
| LED Lamp | 10W*1 | |||
| Blower | Built-in axial flow blower;Speed adjustable. | |||
| Front Window | Manual,5mm toughened glass,height adjustable. | |||
| Power Supply | AC220V±10%,50/60Hz; | |||
| Consumption | 100W | |||
|
Material
|
Main Body | 1.2mm thickness stainless steel with epoxy resin powder coating. | ||
| Inner Side | 5mm thickness compact,resistant to strong acid and alkali. | |||
| Work Table | Chemical resistant phenolic resin, thickness 12.7mm. | |||
|
Standard Accessory
|
LED lamp,Built-in axial flow blower with speed adjustable. | |||
| Waterproof socket*3 | ||||
| 3 meter PP duct,Diameter:250mm | ||||
| Optional Accessory | Outer centrifugal blower(300W),resistant to strong acid,alkali. | |||
| Gross Weight (kg) | 235 | 265 | 300 | |
