Description
The LCD Touch Screen Digital Microscope YR05782 is an advanced laboratory tool featuring a 10.5″ LCD touch screen with an integrated Android system and measuring software. Designed for precision, its high eyepoint wide field eyepiece and achromatic objectives, ranging from 4x to 100x, allow for detailed observations. The microscope is equipped with a double-layer mechanical stage and a 3W LED Köhler illumination system, ensuring consistent and bright image quality. This model is particularly noteworthy for its trinocular head, allowing easy image capture and sharing through its 8.0M digital camera, running on Android 11.
Market Price Estimate
The average market price for high-end digital microscopes like the YR05782 ranges between $1300 and $2100 USD. This makes it a competitive option for laboratories and professionals looking for advanced imaging capabilities without breaking the bank.
Frequently Asked Questions
What are the main features of the YR05782? This microscope includes a high-definition touch screen, advanced measurement software, and versatile imaging capabilities with adjustable settings.
Can this microscope connect to external devices? Yes, it offers multiple connectivity options, such as USB ports, HDMI, and a gigabit LAN port, enhancing its integration with other lab equipment.
Advantages and Disadvantages
Advantages: The YR05782 offers superior image quality due to its advanced optics and digital integration. The user-friendly interface and comprehensive measurement features significantly enhance lab work efficiency.
Disadvantages: Due to its advanced features, there is a learning curve involved in mastering its full potential.
Field Usage
The LCD Touch Screen Digital Microscope YR05782 is ideal for various laboratory applications, including biological research, medical diagnostics, and educational purposes. Its robust design allows for repeated use without compromising on performance or image clarity.
Recommendations
To maximize the performance of your YR05782, regularly calibrate the optics and ensure the software is updated. Proper maintenance of the mechanical stage and careful handling of the touch screen will extend the device’s longevity. For tailored advice or to explore more features, request a quote or generate an automatic quote via the Kalstein Plus platform today.
Features
- 10.5″ LCD touch screen with Android system
- High eyepoint wide field eyepiece
- Achromatic objectives from 4x to 100x
- Double-layer mechanical stage
- 3W LED Köhler illumination
- Trinocular head with adjustable diopter
- Advanced measurement capabilities
- Multiple connectivity options
Technical Specifications
| Model | YR05782 | |
| Head | Trinocular Head, 30° Inclined, Interpupillary Distance 48-75mm, Both Eyepiece Tube Diopter Adjustable | |
| Eyepiece | WF10x/20mm, Diopter Adjustable, Dia. 30mm | |
| Objective | High Contrast Chromatic Free 4x, 10x, 40x(S), 100x(Oil, S) | |
| Focus Knob | Coaxial Coarse & Fine Focusing, Fine Division 0.002mm, Coarse Stroke 37.7mm/Rotation, Focusing Range 24mm | |
| Nosepiece | Quadruple, Backward With Click Stops | |
| Stage | Double Layer Mechanical Stage 142x132mm, Graphite Surface, Moving Range 75x50mm | |
| Condenser | Abbe Condenser N.A.1.25, Center Adjustable | |
| Light Source | 3W LED Brightness Adjustable | |
| Adapter | C-Mount 0.5x | |
| Package | 53*32.5*53.5cm/11.5Kg, 1 Set/Carton | |
| 10.5“ Touch Screen Android Pad Digital Camera, 8.0M1 Newly Update 2022! | ||
| Spec. | Model | YR05782-op0 |
| Category | HD All-in-One Android 11 System Tablet Digital Camera | |
| Sensor | 1/1.8” CMOS Sensor | |
| Effective Pixel | 8M, 4K | |
| Screen | 10.5” High-Definition Touch Screen | |
| Operation System | Android 11 | |
| WIFI | 2.4GHz/5GHz Dual-band WIFI, Support WIFI6 | |
| Bluetooth | Bluetooth 5.0 | |
| Output | USB3.0*2, USB2.0*1, HDMI, Gigabit LAN Port | |
| Pixel size | 2.0um*2.0um | |
| Power | DC-12V/2A | |
| Function | Basic Function | Android Interaction, Installed S-Eye2.0 Measure Software |
| Image Adjustment | Brightness, Contrast, Saturation, Color Temperature | |
| Camera Function | Mirror, Flip, Freeze, Black and White | |
| UI Interface | Support User-friendly Mouse & Keyboard, And Touch Screen Operation | |
| Photo | 8.0M Image Capture | |
| Video | 1080P Video | |
| Storage | Still Photo And Video Recording, Picture Preview | |
| Marking | Point Coordinates, Crosshairs, Coordinate System, Text Annotations | |
| Length Measurement | Straight Line, Folded Line, Curve Length, Parallel Line Distance, Point Line Distance | |
| Geometric Measurement | Line Segment Length, Radius Fixed Circle, 2 Point Fixed Circle, 3 Point Fixed Circle, Concentric Circle, Radius Fixed Circle | |
| Geometric Area Measurement | Polygon, Rectangle | |
| Measurement System | Built-in S-Eye Software | |
| Package | Box Size | 237*169*10.5mm |
| Weight | 0.6kg | |
| Accessory | DC-12V/2A Power Adapter | |
| Laboratory Biological Microscope Optional Accessories | ||
| Eyepiece | WF16X/F.N.15mm | YR05782-op1 |
| WF20X/F.N.12mm | YR05782-op2 | |
| Nosepiece | Backward Quintuple Nosepiece | YR05782-op3 |
| Dark Field | Dark Field Condenser, Dry, N.A.1.25 | YR05782-op4 |
| Dark Field Condenser, Immersion, N.A.1.25~1.36 | YR05782-op5 | |
| Polarizing | Polarizer & Analyzer | YR05782-op6 |
| Phase Contrast | Turret Disc Phase Contrast Condenser, For 10x,20x,40x,100x | YR05782-op7 |
| Infinity Plan Phase Contrast Objective 10x,20x,40x,100x | ||
| Centering Telescope 10x | ||
| Optional For B, T Only | ||
| Adapter | Eyepiece Tube Adapter | YR05782-op8 |
| C-Mount 1.0x | YR05782-op9 | |
