Description
The Portable Conductivity/DO Meter YR06382 is an advanced tool designed for precision and flexibility in environmental testing and laboratory settings. Featuring a large LCD screen with a controllable white backlight, this device ensures easy readability in various light conditions. A built-in microprocessor chip offers intelligent functions such as automatic calibration, automatic temperature compensation (ATC), data storage, and more, making it a versatile choice for professionals who need reliable measurement tools.
Market Price
In the market, the prices for portable conductivity and DO meters like the YR06382 range from approximately $700 to $1200. These prices reflect its enhanced features, precision, and broad measurement ranges. To get an accurate and competitive quote tailored to your needs, you can request a quote through our platform.
Frequently Asked Questions
What is the accuracy of the YR06382 meter?
The meter boasts an accuracy of ±1.0% FS for conductivity measurements and ±0.10 mg/L for DO measurements, making it highly reliable for precise applications.
Does the device support data storage?
Yes, it supports data storage of up to 200 sets, allowing users to keep track of multiple readings efficiently.
Advantages and Disadvantages
Advantages:
- High precision and accuracy for both conductivity and DO readings.
- Automatic and manual temperature compensation enhances measurement reliability.
- Dustproof and waterproof (IP57 rated), suitable for harsh environments.
Disadvantages:
- The advanced features may present a learning curve for first-time users.
- Requires calibration for optimal performance, which may require additional time and resources.
Product Use in the Field
The YR06382 is an ideal choice for fieldwork where precision is critical. Its robust design and IP57 rating ensure that it can withstand challenging conditions, providing accurate measurements in diverse environments such as water treatment facilities, laboratories, and environmental studies. The short polarization time of its polarographic DO electrode stands out during field measurements, ensuring rapid readiness for testing.
Recommendations
To maximize the utility and lifespan of the YR06382, regular calibration and maintenance are recommended. Users should ensure that the device is stored in recommended temperature and humidity conditions and use fresh batteries to maintain consistent performance. Consider training sessions for new users to get acquainted with its advanced features.
Features
- Advanced conductivity measurement technology.
- Switchable among conductivity, TDS, salinity, and resistivity.
- Large LCD screen with white backlight.
- Automatic and manual temperature compensation.
- Data storage capacity for 200 sets.
- Compact and portable design.
Technical Specifications
| Model | YR06382 | |
|
Cond.
|
Measuring range
|
Conductivity: |
| (0.00~19.99)μS/cm | ||
| (20.0~199.9)μS/cm | ||
| (200~1999)S/cm | ||
| (2.00~19.99)mS/cm | ||
| (20.0~199.9)mS/cm | ||
| TDS:(0~100)g/L | ||
| Salinity:(0~100)ppt | ||
| Resistivity:(0~100)MΩ·cm | ||
| Resolution | 0.01/0.1/1μS/cm; 0.01/0.1 mS/cm | |
| Accuracy | ±1.0% FS, Overall:±1.5% FS | |
| Temp. compensation | (0~100)ºC(Auto/manual) | |
| Electrode constant | 0.1 / 1 / 10 cm-1 | |
|
DO
|
Measuring range | (0 ~ 20.00) mg/L(ppm), (0 ~ 200.0)% |
| Resolution | 0.1/0.01 mg/L(ppm), 1/0.1 % | |
| Accuracy | Electrode: ±0.10 mg/L, Instrument: ±0.40 mg/L | |
| Response time | ≤30s (25ºC, 90%response) | |
| Residual current | ≤0.1 mg/L | |
| Temp. compensation | (0 ~ 45)ºC (auto) | |
| Salinity compensation | (0 ~ 45) ppt (auto) | |
| Pressure compensation | (66 ~ 200) kPa (manual) | |
| Auto calibration | Air saturated by water, water saturated by air | |
| Electrode type | Polarographic | |
|
Temp.
|
Measuring range | (0 ~ 100)ºC |
| Resolution | 0.1ºC | |
| Accuracy | 5 ~ 60ºC:±0.4ºC Others: ±0.8ºC | |
|
Other
|
Data storage | 200 sets |
| Power | Two AA batteries (1.5V x2) | |
| Ambient Temp. | 5 ~ 35 ºC | |
| Ambient humidity | ≤85% | |
| IP grade | IP57 Dustproof and waterproof | |
| Dimensions/N.W. | (65×120×31)mm/180g | |
| Shipping size/G.W. | (460×300×55)mm/1Kg | |
