Portable Veterinary Digital X-Ray (DR) for Equine YR06161

ManufacturerKalstein

Description

Animal scientific institution

Only 7 kg weight, easy to use outdoors

Built in large capacity battery can provide more than 200 exposures

Easily connect to tablet through Bluetooth and adjust ray-parameter in real time

6 sets of APR exposure parameter shortcut keys to reduce errors and improve efficiency

It has two kinds of exposure control modes: wireless and wired connection

Ultrasonic measurement of SID

Aplications
  • Racecourse
  • Pasture
  • Veterinary Hospital
  • Zoo
Technical Specifications
Model YR06161
Power Supply AC 220V/110V ±10%
50 / 60 Hz
Power (kW) 1.6
kV 50 ~ 90
mAs 20
mA 20
SID measurement ultrasonic
Light Source On Time(sec) 30
Communication Rs232/Bluetooth
Exposure Hand Switch/315M
Weight (kg) 7
Focal Spot Sizes Tube (mm) 1.2
Target Angle Tube 16°

Additional information

Weight 16 kg
Dimensions 49 × 39 × 39 cm
