| Model |
YR05823 |
YR05824 |
YR05825 |
| External Size (W*D*H) (mm) |
1200*800*1500 |
1500*800*1500 |
1800*800*1500 |
| Internal Size (W*D*H) (mm) |
950*700*1150 |
1250*700*1150 |
1550*700*1150 |
| Work Surface Height |
800mm |
| Max Opening of window |
750mm |
| Air Velocity/Exhaust air volume |
0.4-0.6m/s,800-1000m³/h |
| Noise |
≤60dB |
| LED Lamp |
10W*1 |
| Blower |
Built-in axial flow blower;Speed adjustable. |
| Front Window |
Manual,5mm toughened glass,height adjustable. |
| Power Supply |
AC220V±10%,50/60Hz; |
| Consumption |
85 W |
| Material |
1.0mm thickness SUS304# Stainless Steel. Base Cabinet equipmented with the adjustable mechanism |
| Standard Accessory |
LED lamp,Built-in axial flow blower with speed adjustable. |
| Waterproof socket*3 |
| 3 meter PP duct,Diameter:250mm |
| Optional Accessory |
epoxy resin board or ceramic board.,Water tap,Gas tap,Water Sink |
| Outer centrifugal blower(300W),resistant to strong acid,alkali. |
| Gross Weight |
235 |
265 |
300 |
