Technical Performance and Safety of the YR0242-B Trinocular Microscope
The YR0242-B Trinocular Microscope is a remarkable piece of laboratory equipment that blends advanced optical technology with robust safety features. Designed for both educational and professional use, this microscope provides exceptional image quality and versatility in various applications. In this article, we will explore the technical specifications, performance, and safety features of the YR0242-B, providing insight into its value in the market.
Product Description
The YR0242-B Trinocular Microscope boasts a Seidentopf head with a choice of monocular, binocular, or trinocular configurations. The inclined design at 30 degrees allows for comfortable viewing, while the 360-degree rotating head enhances usability. With adjustable diopter settings of +/-5 in both eyepieces, it accommodates individual viewing preferences.
- Quadruple nosepiece with precise click stop
- Integrated dual-layer mechanical stage measuring 142x132mm
- Focus range of 75x50mm
- Abbe condenser N.A. 1.25 with a high-brightness 3W LED light source, featuring adjustable brightness
- Available with infinite plan optics and achromatic optical system
Seidentopf Head
This microscope features a Seidentopf head, allowing the operator to choose between monocular, binocular, trinocular, and teaching heads. The ergonomic design promotes ease of use and adaptability for various educational purposes.
Quadruple Nosepiece
The microscope is equipped with a quadruple nosepiece that allows for quick and easy switching between objective lenses. It includes achromatic objectives of 4X, 10X, 40X, and 100X (oil immersion), providing a broad range of magnification options.
Dual-Layer Mechanical Stage
The integrated dual-layer mechanical stage enhances stability and precision during specimen examination. With a generous movement range, it allows for easy maneuverability across the specimen for comprehensive analysis.
Condenser and Light Source
The Abbe condenser N.A. 1.25 works seamlessly with a powerful 3W LED light source, providing a bright and clear illumination for detailed specimen observation. The adjustable brightness feature ensures optimal lighting conditions for any sample.
Market Price
The YR0242-B Trinocular Microscope is priced competitively in the market, offering great value for the quality and specifications it provides. The standard retail price is approximately $178.00, making it an accessible option for educational institutions and laboratories alike.
| Feature | YR0242-M | YR0242-B | YR0242-T |
|---|---|---|---|
| Model | YR0242-M | YR0242-B (current) | YR0242-T |
| Video Adapter | —— | C-Mount 0.3x | —— |
| Power Supply Type | AC 110V-240V | —— | —— |
| Light Transmission | Halogen 6V20W or optional LED | ||
| Type of Light Source | Halogen | ||
| Condenser N.A. | 1.25 | ||
| Type of Condenser | Abbe | ||
| Condenser Features | Rack and pinion, filter holder, adjustable centering | ||
| Focusing Scale | 0.002mm | ||
| Focusing Range | 36mm | ||
| Focusing Type | Coaxial coarse and fine | —— | |
| Focusing Features | Adjustable safety stop screw tension | ||
| Stage Working Movement | 75*50mm | ||
| Stage Size | 132*142mm | ||
| Type of Stage | 2 mechanical layers | ||
| Objective | Achromatic 4x, 10x, 40x(S), 100x(O,S) | ||
| Type of Objective | Achromatic | ||
| Objective Holes | 4 holes | ||
| Objective Features | Inward facing | ||
| Eyepiece | WF10x/18mm | ||
| Eyepiece Diameter | 23.2mm | ||
| Inter-pupillary Distance | 54~75mm | ||
| Head Rotation | 360° rotating head | —— | |
| Head Inclination | 30° | —— | |
| Head Type | Monocular | Binocular | Seidentopf Trinocular |
| Standard Magnification | 40x-1000x | —— | |
| Optical System | Achromatic | ||
| Standard Function | BF | —— | |
Frequently Asked Questions
What types of heads are available for the YR0242-B microscope?
The YR0242-B microscope offers monocular, binocular, trinocular, and teaching heads, allowing users to select the configuration that best suits their needs.
What is the maximum magnification of the YR0242-B microscope?
The maximum magnification of the YR0242-B microscope is 1000x, making it suitable for observing fine details in various specimens.
What is the power supply requirement for the YR0242-B microscope?
The YR0242-B microscope operates on an AC power supply ranging from 110V to 240V, providing flexibility for different regions.
What features enhance the safety of the YR0242-B microscope?
This microscope includes adjustable safety stop screws, ensuring secure and controlled focusing to prevent damage to specimens and objectives.
Can the light source be adjusted for different specimens?
Yes, the YR0242-B microscope features an adjustable brightness LED light source, which allows users to modify illumination according to the specific requirements of their specimen.
Is the YR0242-B microscope suitable for educational purposes?
Absolutely! The ergonomic design and versatile configurations of the YR0242-B microscope make it an excellent choice for educational institutions and teaching environments.
Pros and Cons
Pros
- High-quality optical performance with multiple magnification options.
- Ergonomic design for comfortable prolonged use.
- Adjustable brightness and versatile light source for optimal illumination.
- Safe design features, including adjustable stop screws.
- Affordable pricing for the quality offered.
Cons
- Limited to specific applications within laboratory settings.
- May require additional accessories for advanced imaging techniques.
Field Usage
The YR0242-B Trinocular Microscope is ideal for a variety of fields, including biological research, educational institutions, and clinical laboratories. Its adaptability and comprehensive features enhance its usability in different environments, making it an essential tool for scientific investigation and teaching.
Recommendations
To maximize the performance of the YR0242-B microscope, it is recommended to use it in well-lit environments and to regularly maintain the optical components. For educational use, pairing the microscope with high-quality slides and specimens will enable students to fully appreciate the capabilities of this advanced microscope. Additionally, exploring various imaging techniques, such as digital imaging, can further enhance the utility of the YR0242-B in research applications.
If you are interested in acquiring the YR0242-B Trinocular Microscope or have further inquiries, please feel free to request a quote.
