YR01829 Benchtop Conductivity Meter

Manufacturer: Kalstein

Description

The YR01829 Benchtop Conductivity Meter is a state-of-the-art instrument designed to provide precise measurements in a variety of laboratory settings. Featuring a 7-inch colored capacitive touch screen with high resolution and sensitivity, this meter is both user-friendly and technologically advanced. It is equipped with an intelligent microprocessor chip enabling features such as automatic calibration, automatic temperature compensation (ATC), data storage, clock display, USB output, wireless printing, and self-diagnosis. Its advanced conductivity measurement technology ensures accuracy over a broad range, and it offers versatility with capabilities to switch between conductivity, TDS, salinity, and resistivity measurements. Experience the seamless transition of data via optional Bluetooth connectivity and rest assured with its smart electrode status display that guarantees accurate application.

Price in the Market

The YR01829 Benchtop Conductivity Meter is competitively priced in the market, with prices typically ranging from $500 to $800 USD depending on the supplier and additional features offered. This pricing ensures you receive advanced technology and reliability without breaking your budget. To secure this instrument at a competitive rate, consider requesting a quote or generating an automatic quote using our Kalstein Plus platform.

Frequently Asked Questions

Q: Is the YR01829 Conductivity Meter suitable for both laboratory and field use?

A: Yes, its robust design and range of features make it suitable for diverse environments.

Q: How many data sets can the meter store?

A: It can store up to 2000 sets of test data, which can be transferred to a USB memory stick and accessed with Excel.

Advantages and Disadvantages

One of the primary advantages of the YR01829 is its comprehensive feature set, including wireless printing and real-time data transfer, which facilitates seamless operations in different lab scenarios. Its intuitive touch screen and smart electrode status display enhance user interaction and accuracy. However, users should ensure compatibility with their specific operational environment, as the advanced technology may require appropriate training to fully utilize.

Product Use in the Field

The YR01829 Benchtop Conductivity Meter is designed for easy use in real-world applications. In laboratory settings, it is ideal for measuring various parameters such as pH, mV, conductivity, and more, thanks to its automatic calibration and temperature compensation features. These make it suitable for industries ranging from pharmaceuticals to environmental monitoring.

Recommendations

To get the most out of your YR01829 Conductivity Meter, regular calibration and maintenance are recommended. Take advantage of its data storage capabilities to track long-term trends, and use the Bluetooth feature for efficient data handling. Familiarize yourself with its settings to maximize accuracy and responsiveness in your specific applications.

Features

  • 7-inch colored capacitive touch screen with high resolution and sensitivity.
  • Built-in microprocessor chip with intelligent functions.
  • Wireless Bluetooth printing and real-time data transfer.
  • Smart electrode status display for accurate use.
  • Advanced conductivity measurement technology.
  • Supports multiple measurement modes with precision conversions.

Technical Specifications

Model YR01829
pH Measuring range (-1.999 ~ 19.999)pH
Resolution 0.1/0.01/0.001 pH
Accuracy Electrode: ±0.002 pH, Meter: ±0.01 pH
Auto calibration 1, 2, 3 point
Buffer Europe & USA, NIST, China standards
Input current ≤1×10 -12 A
Input impedance ≥3×10 12Ω
Stability ±0.002 pH/3h
Temp. compensation (0 ~ 100)°C, auto or manual
mV Measuring range -1999.9mV ~ 0 ~ 1999.9mV
Resolution 0.1 mV
Accuracy ±0.03% FS
Cond. Measuring range Conductivity
(0.00~20.00)μS/cm, (20.0~200.0)μS/cm
(200~2000)μS/cm, (2.00~20.00)mS/cm
(20.0~200.0)mS/cm
(200~2000)mS/cm (K=10)
TDS: (0 ~ 100)g/L
Salinity: (0 ~ 100)ppt
Resistivity: (0 ~ 100)MΩ·cm
Resolution 0.01/0.1/1μS/cm; 0.01/0.1/1mS/cm
Accuracy Electrode: ±0.5% FS, Meter: ±0.8% FS
Temp. compensation range (0 ~ 100)°C, auto Electrode constant 0.1/0.5/1/5/10/50/100 cm -1
Reference Temp. 25°C, 20°C, 18°C
Temp. Range (-10 ~ 110)°C
Resolution 0.1°C
Accuracy 5 ~ 60°C:±0.4°C Others: ±0.8°C
Other Display 7-inch colored capacitive touch screen
Data storage 1000 sets
Power 12V/1A
Output USB
Ambient Temp. 15 ~ 30 °C
Ambient Humidity ≤85%
IP grade IP54
Dimensions/N.W. 215×170×37mm/600g
Shipping Size/G.W. 470x430x72mm/3kg

Additional information

Weight 3 kg
Dimensions 47 × 43 × 8 cm
