Manufacturer: Kalstein
YR02154 surgical operating table is a universal electric operating table that allows all kinds of surgical positions. Based on the highly reliable and stable electro-hydraulic system, it can be easily set up and precisely positioned with ultra low noise. With integrated one key reset function, handheld panel, standby control panel in the column and foldable head plate for greater rest, the surgical operating table will bring great operation convenience and surgical experience for both surgeons and patients.
YR02154 is an electro-hydraulic operating table designed to meet universal surgical-positioning needs, like in Neurology, Ophthalmology, Gynecology, Urology, Minimal Invasive Surgery, Hand & Arm surgery ..
Model | YR02154 |
Table length | 2100 mm |
Table width | 500mm (not include side rail) |
Table height (up / down) | 1030mm / 700mm |
Trendelenburg / Reverse Trendelenburg | 30 ° / 30 ° |
Lateral tilt (right / left) | 20 ° / 20 ° |
Back plate (down) | 68 ° / 42 ° |
Head plate (down) | 57 ° / 72 ° |
Leg plate (downlsplit) | 96 ° / 65 ° x 2 |
Flexion / Reflection | 220 ° / 115 ° |
Longitudinal displacement | 296 millimeters |
Patient weight | 200Kg (during positioning) |
Input power | AC 110 / 220V, 60 / 50Hz |
Weight | 285 kg |
---|---|
Dimensions | 132 × 77 × 107 cm |
