Microplate Washer

The importance of the microplate washer is that during the ELISA a microplate washer is responsible for removing unbound material and reagents that have not reacted. Washing is a critical stage in the performance of the technique.

It is extremely essential not only to respect the number of wash cycles and buffer volumes in each well. The soaking time is standardized to reduce the interference produced by the samples, as well as to eliminate the conjugate not specifically bound to the reaction, and its objective is to provide sufficient time to allow the diffusion of the components to be eliminated in the buffer, thus making the washing performance more optimal. The washing processes carried out in the ELISA microplate washer include the following: top-down suction, simultaneous suction and dispensing and suction from the bottom of the wells.

Types of Microplate Washing Machine a Laboratory May Need

Microplate Washer YR05125

● Compatible with Flat, U-or V-bottom plates
● Shaking or soaking, time can be adjustable
● Waste and lotion and distilled water liquid warning....


Microplate Washer YR05124

● 8-well and 12-well wash head
● One or more strips can be chosen by keyboard directly
● Compatible with Flat, U-or V-bottom plates...


Microplate Washer YR05126

●96-well head
● single needle recoil, no aspirating needle, no blocking
● Wash time is less than 30 seconds for one plate...


Our Best Selling Microplate Washing Machine

Model YR05126
Washing head 96 needle
Washing wells 24,48,72,96 wells optional, can continuous arrange the wells, no interval
Micro-plate type Flat, Round, U, V
Washing mode Single plate (A or B), double plate (A-B)
Lotion A,B
Washing time 1-999 times adjustable, step 1s
Flusting time 0-999 seconds adjustable, step 1s
Pressure setting 0-9.9 adjustable
Centrifugal time 0-999 seconds adjustable, step 1s
Centrifugal rate 1200-2500rpm
Residual liquor ≤0.1uL per well
Washing head position 0-10.00mm continuously adjustable, completely washing
Liquid level induction insufficient washing and distilled water alarm
Capacity bottle 2pcs 10000mL bottles for lotion, 1 pc for distilled water, another for waste
Screen 7 inches color touch screen operation, convenience and efficient with low failure rate
Power supply SMPS: 110/220V±10%, 50/60Hz±1Hz
Working condition Temp. 5℃-40℃;Relative humidity: ≤80%
Dimensions 51CM(L)*51CM(W)*43CM
Weight 30KG


Analysis of the best Microplate Washing Machine for your laboratory

Is an Elisa Microplate Washer Important?

The importance of the Elisa technique, has to do with the detection of diseases until quantification by ...


How many types of Microplate Washer are there?

The microplate washer is a device that is usually used in laboratories, to remove any substance that has been adhered ...


How does an Elisa Microplate Washer work?

It is a laboratory device used to perform automatic washing operations on microplates. They are used for studies and...


What is an ELISA reader used for?

An ELISA reader is a specialized spectrophotometer used to read the results of this technique, which is used...


Guides to becoming an expert in Microplate Washing Machine

Microplate Washing Equipment are essential products in a laboratory, we provide guides and recommendations for better use, so you can work as an expert.

Microplate washer for ELISA: What types exist?

An ELISA microplate washer is a laboratory equipment used to perform washing operations in the ELISA technique....

Why is a microplate washer important?

A microplate washer is a laboratory instrument used to perform washing operations during the ELISA technique. Washing...

What are the differences and applications between the microplate reader and microplate cleaners?

A microplate reader or photometer, is a laboratory team that discovers biological, chemical or physical anomalies of a sample, such as the presence of antibodies or specific antigens, such as yellow fever, HIV, dengue, among others, in the field of immunology and serology...

Frequently Asked Questions about Microplate Washing Machine

To know the price of Microplate Washing Machine we invite you to send us an email with your request through the contact form.

The delivery time of your Kalstein product will depend on the following:
  1. If the equipment of your interest is in stock or if it must be manufactured.
  2. The type of freight you have chosen, this may be; air or sea.
  • Equipment in stock:
- Delivery Time (Air): 15-30 days.


- Delivery Time (Maritime): 45-60 days.
  • Equipment not in stock:
- Delivery Time (Air): 30-60 days.
- Delivery Time (Maritime): 60-90 days.
You can make your purchase through:
  1. By email: sales@kalstein.eu
  2. By telephone: +33 (0) 1 78 95 87 02
  3. E-commerce: Via Kalstein's official website in your country.
All Kalstein equipment has a 1-year warranty against manufacturing defects. The warranty does not cover damage caused by poor installation or operation by the user, transport defects or by uses other than those specified by the manufacturer. Warranty excludes electrical or consumable parts. For more information visit our “terms and conditions” by clicking HERE


At Kalstein, we provide our customers with induction and technical support through new online methods. You can visit our induction videos, technical assistance and guidance provided by a Kalstein team through our YouTube channel (Kalstein English). HERE

Of course, you can request a quote for the Kalstein team of your interest, directly from our official website. Once you have identified your preferred model, click HERE
