In a laboratory it is really important to understand the usefulness of each equipment, in the case of reagent analyzers, the analyzers are classified according to the tests that are required, the results that are desired to obtain, the automatic analyzers of laboratories, allow to facilitate the functions that are performed in it, the manufacturer of the analyzers is also part of the advantages and guarantees of each device, that is why in KALSTEIN, being manufacturers we guarantee them equipment of excellent quality.
Laboratory analyzers can have a wide classification and at the same time these have subcategories, these teams perform analyzes through substances or samples, using reagents; in the case of KALSTEIN, we offer an interesting range of laboratory analyzers, which cover the most demanding requirements of any laboratory, yielding the most effective and accurate results.
In addition to being a team that allows to determine certain diseases, it aims to offer a high capacity diagnostic platform to which can be linked to other analytical modules: biochemistry, immunology, among others; some options offered by hematology analysers are:
this equipment offers an advantage in the routine work of a laboratory, and although it can be a long process and with certain quality requirements, the possibilities of this equipment are immense such as facilitating the readings of concentration, total motility, progressive motility and sperm kinetics, performing chemical tests and immunoassay for seminal plasma
KALSTEIN ANALYZERS
There are a lot of models, so it's normal that you don't know which Analyzers to buy to meet your needs. At Kalstein, we evaluate you to find what you're looking for.
Automatically absorbs excess urine, prevents cross contamination of urine samplesBuilt-in thermal printer, with outer...
80 test item pre-programmed
Memory for 10,000 sample results,Light source hibernate function...
8.4” color TFT screen, all testing parameter displayed simultaneously,Windows operation system, mouse...
Chemistry Analyser: the use of this type of analyser is to detect existing metabolites in biological samples: blood or urine, the study of these fluids allows the doctor to diagnose diseases, this analyser is used for measuring creatinine in the urine to check the filtration capacity of the kidneys.
| Model | YR05123 |
| Equipment type | fully automatic discrete, STAT priority |
| Analysis rate | constant speed 200T/H (without ISE) |
| Test principle | colorimetry, turbidimetry |
| Analysis method | end-point, 2 kinetics, fixed-time, etc. support single/double wavelength, linear and non-linear calibration |
| Sample system: | |
| Sample tray | 42 sample positions, random access of all samples |
| Sample volume | 2-50ul, 0.1ul increment |
| Sample probe | liquid level detection, the remaining detection, collision protection etc. |
| Sample containers | sample cups. |
| Reagent system: | |
|
Reagent tray |
25 reagent positions |
|
Reagent volume |
R1:25-300uL, R2: 10-150uL, 0.1uL increment |
|
Reagent probe |
liquid level detection, the remaining detection, collision protection etc. |
|
Reagent refrigeration |
4-15℃,independent power supply, 24-hour non-stop refrigeration |
| Reaction system: | |
| Reaction tray | rotating tray, 120 cuvettes |
| cuvette | reusable high quality cuvette, optical diameter 6mm |
| Reaction volume | 180-500uL |
| Incubation system | bi-directional liquid-air device |
| Temperature | 37℃±0.1℃ with real-time display |
| Optical system: | |
| Light source | 12V35W halogen lamps, over 2000 hours |
| Photoelectron road | after spectrophotometry |
| Wavelength | 340, 405, 450, 510, 546, 578, 630, 700nm |
| Absorbance range | 0-3.500Abs |
| Resolution | 0.0001Abs |
| Operating system: | |
| PC operating system | windows XP or above |
| Analysis control software | English version graphical operating software |
| Report printing | report formats support the user-defined mode, QC and state information etc. |
| System connection | RS-232 |
| Working Conditions: | |
| Power supply |
AC 220V±22V, 50Hz±1Hz, power 1.5KVA |
| Ambient temperature | 15-30℃ |
| Humidity | 35-80% |
| Water consumption | 5L/Hour |
| Dimension | Bench top: 750mm*520mm*600mm |
| Weight | 45kg |
Blood chemistry analyzers are clinical laboratory equipment, essential for the medical area, because through...
A coagulation analyser is a laboratory equipment by which clotting factors, essential elements required...
Hematology analyzers are equipment used to perform complete blood counts, or blood counts. They do...
The health processes and medical analysis performed by a patient to diagnose diseases are a wide range...
Coagulation analyzers are laboratory tools that speed up analysis of clotting factors, which represent proteins...
Nowadays, with the technological advances of medicine, health care requires the exchange of different disciplines...
This type of analyser is also known as biochemistry analyzers, they are required equipment to determine the...
An analyser is a technological device of clinical laboratory, designed to calculate different chemical samples and other characteristics, in a number of biological samples with minimal human assistance. These measurements of blood and other fluids can be used...
In this section you can find, our Analyzers in operation, packaged, receiving service, etc.
According to their performance, the laboratory analyzers are classified into two automatic and semi-automatic models, according to the manufacturer, the differences between the analyser equipment is in the technical sheet or individual characteristics of the equipment, what is important is to have a reliable manufacturer that can give immediate answers to possible doubts or technical failures of the equipment; in this case we at KALSTEIN offer you high-end equipment and warranty with European recognition.
In a laboratory it is really important to understand how each equipment works, in the case of laboratory analyzers, the analyzers are classified according to their operation in : automatic and semi-automatic
To know the price of the analysers we invite you to send us an email with your request through the contact form.
Of course, you can request a quote for the Kalstein team of your interest, directly from our official website. Once you have identified your preferred model, click HERE
