Semi-auto Chemistry Analyzer YR05116

Manufacturer: Kalstein

Description

  • Windows Operating System with large touchscreen
  • Displays the reaction curve in real time
  • Adjustable continuous wavelength grille, improves stability and reliability
  • The open reagent system supports both flow cell and cuvette mode, with a closed system available on demand
  • Analytical modes include kinetic end point, fixed time, bicrobatic with or without sample blanking, non-linear absorption control
  • Large memory, able to store up to 200 test protocols and 10,000 results
  • Powerful QC program, several Westguard rules, Levey-Jennings plots, 2 controls per test
  • Results in various formats including comprehensive patient report
  • Supports multiple interfaces RS-232.VGA.USB.SD and Ethernet
  • Easy PC communication
  • Compact design enables USER-DIY maintenance
  • Software languages available on demand

Technical Specifications

Model YR05116
Absorbance Range -0.500 – 3.500Abs
Resolution 0.001Abs(displayed), 0.0001Abs(calculated)
Light Source Halogen Lamp, 12V/20W
Wavelengths Continuously adjusted grating, wavelength range is 330 – 800m, 1m per step adjustment
Wavelength Accuracy ยฑ 1nm
Bandwidth < 6nm
Flow Cell Metal – quartz flow cell
Temperature Control 25 ยฐC, 30 C, 37 C. ยฑ 0.1 C and ambient temperature
Cross Contamination Rate < 1%
Display 6.4* color/mono LCD
Output Built-in printer or external printer
Input Touch screen, optional mouse and keyboard
Interface RS-232, VGA support,2 USB,SD,Ethernet
Language English or any other language upon request
Power Supply AC 110V/220V ยฑ 10% , 50 60Hz
Net Weight 13,5K
Dimensions L x W x H (mm) 370 ร— 284 ร— 318

Additional information

Weight 13,5 kg
Dimensions 53 × 42 × 44 cm
